Max. Cont. Current (A): | 135A |
Weight (g): | 105 g |
Motor Limit: | Brushless Motor Limit with 2S LiPo / 6 Cell NiMH: KV=6000 (3656 size motor) Brushless Motor Limit with 3S LiPo / 9 Cell NiMH: KV=4000 (3656 size motor) Brushless Motor Limit with 4S LiPo / 12 Cell NiMH: KV=3000 (3656 size motor) |
Input Voltage (V) min. - max.: | 7.4 - 14.8V |
Max. Current (A): | 830A |
Length (mm): | 49.0mm |
Nr of Li-xx Cells: | 2-4S LiPo |
Width (mm): | 39.5mm |
Nr of Ni-xx Cells: | 6-12 Cells |
Height (mm): | 34.7mm |
BEC Voltage (V): | 6-7.4V programmable |
BEC Current (A): | 4A |
Lipo Cut off: | Programmable |
Thermal Protection Temperature: | 105°C / 125°C programmable |
Water Protection: | Yes |
Cooling Fan: | 25x25x10mm |
Connector (Motor): | 4.0mm female |
Connector (Battery): | XT90-connector |
Battery wire size: | 12 AWG |
Car Type Use: | 1/10 - 1/8 scale |
